Lecture 12 – Data Warehousing and OLAP for Data Mining

Lecture 12 explains Data Warehousing & OLAP for Data Mining, covering architecture, ETL processes, star/snowflake schema, multidimensional models, OLAP operations, cubes, case studies, and real-world applications.

Data Mining is only effective when the underlying data is integrated, clean, consistent, and well-organized. In enterprise environments, data comes from dozens of systems billing, CRM, ERP, social media, apps, IoT sensors, and external sources.
To analyze this information efficiently, organizations use data warehouses and OLAP systems.

This lecture provides a deep understanding of:

• Data warehouse architectures
• ETL pipelines
• Multidimensional cubes
• OLAP operations
• Schema design
• Industry use-cases

It prepares students to handle real-world analytical systems used by banks, hospitals, retail giants, governments, and tech companies.

Introduction to Data Warehousing

Why Data Warehouses Exist

Operational databases (OLTP) are designed for transactions, not analytics.
Example OLTP tasks:

• Insert new orders
• Update stocks
• Process payments

But they cannot efficiently handle:

• Trend analysis
• Sales comparisons
• Seasonal behavior
• Multi-year predictions

That’s why Data Warehouses are built.

Differences Between OLTP & OLAP

Feature	OLTP	OLAP
Purpose	Daily operations	Analysis & Decision Making
Queries	Simple, short	Complex, long
Speed	High	Medium
Data Type	Current	Historical
Users	Clerks, Cashiers	Analysts, Managers
Example	ATM system	Business analytics dashboard

Data Warehouse Architecture

Single-Tier Architecture

Goal: Minimize redundancy by storing everything in one place.
Not commonly used.

Two-Tier Architecture

Client ↔ Server
Used for small-scale warehouses.

Three-Tier Architecture (Most Common)

Tiers:

1. Bottom Tier (Data Warehouse Server)
   • Stores integrated warehouse data
2. Middle Tier (OLAP Server)
   • MOLAP
   • ROLAP
   • HOLAP
3. Top Tier (Front-End Tools)
   • Dashboards
   • Analytics
   • Reports

Components of a Data Warehouse

Data Sources

Examples:

• ERP systems
• CRM
• Web logs
• IoT sensors
• Social media

ETL (Extract, Transform, Load)

Extract

Pull data from source systems.

Transform

Clean, standardize, convert, merge.

Load

Insert into warehouse.

Text-based ETL Diagram

Source → Extract → Transform → Load → Warehouse → OLAP → Reports

Staging Area

Temporary storage for transformation before loading.

Metadata Repository

Stores:

• Data descriptions
• Business rules
• Table mappings

Data Marts

Small, department-specific warehouses.
Examples:

• Marketing mart
• Finance mart
• Sales mart

Lecture 11 – Ethical Legal and Privacy Issues in Data Mining

Multidimensional Data Model

A warehouse organizes data using cubes.

Cubes

A cube is a multidimensional dataset used for analysis.

Example Cube Dimensions:

• Time
• Product
• Region

Dimensions

Attributes used for analysis.

Example:

Time → Year, Quarter, Month, Day
Product → Category, Brand, Item
Region → Country, State, City

Measures

Numerical data for analysis:

• Total sales
• Profit
• Quantity

Fact Table & Dimension Table

Fact Table:

• Contains measures
• Example: sales_amount, units_sold

Dimension Tables:

• Describe business entities
• Example: dim_product, dim_customer

IBM Data Warehousing Guides

Star Schema vs Snowflake Schema

Star Schema

• Central fact table
• Surrounding dimension tables
• Simple and fast

Diagram:

         dim_customer
               |
dim_time — fact_sales — dim_product
               |
         dim_region

Snowflake Schema

Dimensions broken into sub-dimensions.

Example:

dim_location → country → state → city

More normalized but slower.

OLAP: Online Analytical Processing

OLAP allows fast analysis using cubes.

MOLAP

• Multi-dimensional OLAP
• Data stored in optimized cube format
• Fastest queries

ROLAP

• Relational OLAP
• Uses relational DB tables
• Scalable but slower

HOLAP

• Hybrid OLAP
• Combines MOLAP + ROLAP

OLAP Operations

Roll-Up (Aggregation)

Going from detailed data → summarized data.

Example:

Day → Month → Year
City → Country

Drill-Down (Reverse of Roll-Up)

Going from summarized → detailed.

Example:

Year → Quarter → Month → Day

Slice

Selecting a single dimension.

Example:

Only 2023 data

Dice

Selecting multiple dimensions.

Example:

2022 & 2023 + Product A + Region Asia

Pivot

Rotating cube view to see data from a new angle.

Warehouse Design Process

Requirements Collection

Meet stakeholders to define analytical needs.

Dimensional Modeling

Design fact & dimension tables.

Building Cubes

Define:

• Measures
• Dimensions
• Aggregations

Case Studies

Retail Industry (Walmart, Amazon)

Used for:

• Product demand forecasts
• Store performance
• Customer segmentation
• Basket analysis

Banking

Used for:

• Fraud detection
• Customer insights
• Credit scoring

Healthcare

Used for:

• Patient analytics
• Disease surveillance
• Hospital workflow optimization

How Warehousing Supports Data Mining

Improved Data Quality

Cleaning + integration ensures high-quality data.

Efficient Query Processing

Cubes enable fast aggregations.

Clean & Integrated Data

Data mining models perform better.

Summary

Lecture 12 explained the foundation of Data Warehousing & OLAP for Data Mining. Students learned about architectures, ETL, dimensional modeling, star/snowflake schema, cubes, OLAP operations, and industry use cases. This prepares learners to handle large-scale analytical environments and supports future advanced mining projects.
